18000BPH PLC Noni Juice Concentrate Machine RCGF Mango

Name: 18000BPH PLC Noni Juice Concentrate Machine RCGF Mango
Brand: Aquatrin
Price: 12000 USD

Best 18000BPH PLC Noni Juice Concentrate Machine RCGF Mango wholesale

Brand Name : Aquatrin

Model Number : RCGF

Certification : ISO CE

Place of Origin : China

MOQ : 1unit

Price : USD12000-50000 1Set

Payment Terms : L/C, T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Automatic Grade : Automatic

Operate : Touch screen, PLC control

Applicable Industries : Food & Beverage Factory

PLC brand : Mitsubishi

Operation : PLC control

Others : mango pulp manufacturing process

Contact Now

Automatic Rotary Type PET bottle Washing Filling Capping 3 in 1 Machine.

● Bottle is entered by air conveyor, the speed of bottle entering is fast and bottle shape is not changed because of adopting hanging clamping bottleneck way.
 ● Adopting clamping bottleneck way to wash bottle mouth and avoiding touch screw mouth, adopting clamping bottleneck way in the whole conveying process. When bottle type changes, you need to change the board related with bottle diameter.
 ● Filling adopts cylinder feeding structure, filling valve adopts high filling speed and mass flow rate valve which control liquids level accurately and without loss.
 ● The capping system applies advanced French technology, when clamp the cap will screw immediately and magnetic torque type capping head.
 ● Main PLC and frequency changer are used famous brand, such as Mitsubishi and Omron etc.

Final Products

18000BPH PLC Noni Juice Concentrate Machine RCGF Mango

Product Paramenters

Model	Rated Capacity/BPH	Size/mm	Weight/T
RCGF14-12-5	3000-4000	218015602300	3
RCGF18-18-6	5000-6000	235019002300	3.5
RCGF24-24-8	8000-10000	290020002300	5
RCGF32-32-10	12000-15000	350028502300	7
RCGF40-40-12	15000-18000	450037502300	10
RCGF50-50-12	18000-22000	520040002300	12
RCGF60-60-15	20000-25000	550045002300	15

Details Images
Washing Heads.
* Adopting the direct connection technology between the air duct and the bottle feeding wheel, the bottle feeding screw and conveyor chain are eliminated, and the bottle shape is simple and easy to change. * Bottle transmission adopts the bottleneck clamping technology throughout the whole process. Changing the bottle shape does not need to adjust the height of the equipment. It only needs to replace the arc guide plate, dial wheel and other nylon parts related to the bottle diameter. * The high-speed line adopts bottle clamp transmission technology, the bottle shape changes more freely, and the internal working surface of the unit is more concise.
Filling Heads.
* The three-in-one unit completes the three processes of bottle washing, filling and capping at one time, with little bottle wear, accurate and stable transmission, and convenient bottle type replacement. * The specially designed all-stainless steel bottle washer bottle clamp is sturdy and durable, and does not touch the threaded part of the bottle mouth to avoid secondary pollution of the bottle mouth. * High-speed and large-flow gravity filling valve, fast filling speed, accurate liquid level without liquid loss.
Capping Heads.
* All parts in contact with liquid are made of high-quality stainless steel materials or food-grade engineering plastics, which meet the national food hygiene standards. * The bottle bottom support plate of the bottle output wheel adopts a spiral descending method, and the height of the bottle conveyor chain is not required to change the bottle shape.
  Beverage pre-treatment system:
<1> The beverage processing system applies to beverage processing for hot filling line and CSD filling line.
 <2> product's scope hot water system, sugar dissolving system ( simple syrup system ), concentrate system, blending system (final syrup system), CIP system, extraction system, kind of storage tank / valves / pipe / fittings, UHT system (plate / tubular type), and carbo-cooler / mixer (manual / automatic)
 Tube UHT Sterilizer.
The tube(pipe) sterilize machine can take hot process on the liquid foods and beverage.
 Bottle Inverse Sterilizer Machine.
It is mainly used in sterilizing PET bottle mouth and inside surface of caps. in which haven't been disinfected by themal tea,fruit juice which having been filed in PET bottle.
 CIP Cleaning system
CIP plays role of rinsing syrup melting system, extracting and dispensing system for juice, homogenizer, and air exhauster. UHT sterilization system is attached with the CIP.
